We have large front tires, which while excellent in helping our spirited driving, have always had their downsides, e.g. cost when replacing, tire noise, and at very low speeds while making steering wheel lock turns, can produce tire "chatter, skipping, jerkiness" etc.

Thanks to GM TechLink, we have more information as to whether the tire chattering on your Corvettes is normal, or a symptom of another problem, such as a rear differential issues (funny how what many Corvette owners have "known" we have is a front end steering problem, yet one that has turned out to be a rear differential issue). Here the latest GM TechLink on this issue.

"« Rough Idle ConditionElectrical Diagnositc Test Probe and Terminal Release Tool Kits »
Corvette Tire Chatter: December 5, 2013
The Corvette always has been built to perform. Part of the ride and handling equation is the high-performance tires available on recent Corvettes.


The 2014 Corvette is equipped with standard P245/40ZR18 front and P285/35ZR19 rear performance summer-only tires and the Z51 Performance Package includes P245/35ZR19 front and P285/30ZR20 rear Michelin Pilot Super Sport ZP summer-only tires. (Fig. 9) These tires may have a chatter noise during low speed turns.

(Similarly), the tread design of the Goodyear F1 tires on the 2011-2013 Corvette Grand Sport and Z06 models also is more susceptible to tire chatter or hop than the tread design on previous F1 tires.

Tire chatter noise, caused by the large amount of tire scrubbing across the pavement, occurs most often during low speed, tight turns (in all directions) when the tires are cool, usually after an extensive ambient soak of the vehicle. The chatter typically diminishes when the tires warm up, but may increase on wet pavement. This is a normal characteristic of the high-performance tires.

It’s important not to confuse a tire chatter condition with a possible rear differential chatter noise.

A vehicle soak of at least eight hours during cool ambient temperatures is required prior to evaluation on a clean, dry asphalt or concrete road surface. There should be sufficient space for two to three full vehicle turns at idle speed. Limit the evaluation to no more than four full vehicle circles.

To evaluate the noise condition:
1. With the engine running and the vehicle at rest, turn the steering wheel until full steering lock is achieved.
2. Shift into gear. The noise should be heard once the vehicle has made one to two circles.
3. With the vehicle moving in a tight circle and the noise present, move the steering wheel in 1/4 turn increments away from the full lock position. A maximum of 1/2 to 3/4 turn should be sufficient to determine the source of the noise.
4. Place a hand at the 6 o’clock position as a reference indicating full lock. Move the steering wheel to the 3 or 9 o’clock position and hold it for two to three seconds. Repeat if necessary for a maximum of four complete vehicle circles.

If the noise is caused by front tire hop, it will reduce in severity or cease during the turning sequence as soon as the steering wheel is turned. A 1/4 steering turn will usually dramatically reduce front tire chatter.

If the noise is caused by rear differential chatter, it will not be reduced in severity when turning the steering wheel, but may be reduced in frequency. If the differential is the cause of the noise, refer to Rear Drive Axle in the appropriate Service Information.

For additional information, refer to Bulletin #09-04-20-001D and to the May 2010 Emerging Issues seminar, course number 10210.05.

– Thanks to Jeremy Richardson and Art Spong"


·
Registered
Joined
·
4,607 Posts
We need to put all these tire "issues" in one package if that is possible. Right now there are at least 3 threads on this topic that I can think of. Not sure how we would do that and have it make sense, but maybe we should try.


·
Registered
Joined
·
4,607 Posts
Steve; Thanks. That is good link, but it only explains "front tire" issues. There are some owners that are reporting that the noise coming from their cars is coming from the rear. If this is true, I believe this make it a rear diff. issue. I am trying to get a handle on whether or not the owners reporting this rear end noise own Z-51 optioned cars. If so, then that may point a finger of concern towards the operation of the E-Diff unit in the Z-51.
